Sheet Metal Fabrication Services

Precision Fiber Laser Cutting for Steel & Aluminum

Our fiber laser cutting services deliver precise, burr-free sheet metal parts for prototypes, low-volume manufacturing, and high-volume production. We laser cut steel up to 20 mm thick and aluminum up to 12 mm, with positional accuracy down to ±0.02 mm.

Our 30-fiber-laser production facility supports precision sheet metal cutting, flat-sheet profiling, fine-feature laser cutting, and high-volume nesting for efficient material utilization and consistent part quality. Finished parts come off the laser cutting table clean and burr-free, minimizing or eliminating secondary deburring and cleanup before bending, welding, or other downstream operations.

Steel laser cutting: Up to 20 mm thickness

Aluminum laser cutting: Up to 12 mm thickness

Positioning accuracy: Up to ±0.02 mm

30 fiber laser machines for scalable production

Fine-feature and precision laser cutting

High-volume sheet nesting for efficient material utilization

Burr-free parts ready for bending, welding, assembly, or finishing

Our CNC waterjet cutting services process materials that can be difficult to cut with laser or plasma, including titanium, copper, stainless steel, and heat-sensitive alloys. We cut metal and sheet materials up to 150 mm thick, with edge accuracy down to ±0.1 mm.

As a cold-cutting process, waterjet cutting generates virtually no heat-affected zone (HAZ) or thermal distortion. This helps preserve the original material properties and dimensional integrity of your parts, reducing the need for additional heat treatment or secondary correction before assembly.

Cutting thickness: Up to 150 mm

Edge accuracy: Down to ±0.1 mm

Process: Cold waterjet cutting with minimal thermal impact

Materials: Titanium, copper, stainless steel, and heat-sensitive alloys

Applications: Precision prototypes, custom metal parts, thick plate cutting, and production components

Post-processing: Parts can proceed directly to machining, finishing, or assembly with minimal thermal correction

Our CNC plasma cutting services provide fast, economical cutting for carbon steel, stainless steel, and aluminum plate up to 50 mm thick. Plasma cutting is ideal for structural metal parts, brackets, frames, base plates, and heavy-duty components where cutting speed and production efficiency are more important than ultra-fine feature detail.

With high cutting speeds and efficient material removal, plasma cutting is well suited for low-volume prototypes and high-volume production runs. Clean, consistent cut edges help minimize secondary processing and allow many parts to move directly to welding, fabrication, and assembly.

Cutting thickness: Up to 50 mm

Materials: Carbon steel, stainless steel, and aluminum

Process: CNC plasma cutting

Best for: Structural parts, brackets, frames, base plates, and heavy-duty components

Key benefits: Fast cutting, cost-effective production, and high material removal rates

Downstream processing: Cut parts are suitable for welding and fabrication with minimal secondary preparation

Our CNC press brake bending services form precise bends, flanges, channels, and other sheet metal features in materials from 0.5 mm to 6 mm thick. We maintain bend angle tolerances of ±0.5° and positional accuracy down to ±0.05 mm across production runs, delivering consistent, repeatable sheet metal parts.

Before production, our engineers provide a free DFM review to verify critical bending parameters, including bend radii, minimum flange lengths, bend sequences, and springback compensation. This helps prevent forming issues, reduce rework, and ensure your parts meet design requirements from the first production run.

Material thickness: 0.5–6 mm

Bending process: CNC press brake bending

Bend angle tolerance: ±0.5°

Positional accuracy: ±0.05 mm

Capabilities: Bends, flanges, channels, and complex sheet metal forms

Free DFM review: Bend radii, flange lengths, bend sequence, and springback compensation

Applications: Prototypes, custom sheet metal parts, and production runs

Our metal stamping services produce precision sheet metal parts with holes, slots, embossments, flanges, and formed features at high production speeds. We offer both progressive die stamping and single-station stamping for production volumes from 1,000 to 500,000+ parts, with consistent dimensional accuracy and repeatability across production runs.

Our in-house stamping die design and manufacturing capabilities help shorten tooling lead times, improve production control, and reduce overall per-part costs. From simple stamped components to complex formed sheet metal parts, we provide scalable high-volume metal stamping solutions for automotive, electronics, industrial, and consumer products.

Stamping processes: Progressive stamping and single-station stamping

Production volume: 1,000 to 500,000+ parts

Capabilities: Holes, slots, embossments, flanges, bends, and formed features

Tooling: In-house stamping die design and manufacturing

Benefits: High-speed production, consistent accuracy, and competitive unit costs

Applications: Automotive, electronics, industrial equipment, appliances, and consumer products
